Description
[Zipp Air Impact Comparison Chart]
FEATURES
- Adjustable 3 stages speed for Forward/Reverse.
- ZIW440 was designed to be compact and durable.
- Excellent power-to-weight ratio in its class.
- Used for heavy automotive and truck repair, construction or assembly line.
- Extremely durable Twin Hammer Mechanism.
- More torque with less vibration.
SPECIFICATIONS
| Brand Name | Zipp Air Tool USA |
| Item model number | ZIW440 |
| Square Drive | 1/2″ (12.7mm) |
| Std. Bolt Size | 5/8″ (16mm) |
| Free Speed | 11,000 rpm |
| Max. Torque (10 Sec) | 400 ft-lb (543nm) |
| Operating Air Pressure | 90psi (6.2bar) |
| Avg. Air Consumption | 7cfm (200 l/min) |
| Net Weight | 3.3lb (1.5kgs) |
| Air Inlet Size | 1/4″ NPT/PT |
| Min. Hose size | 3/8″ (10mm) |
[Back To Top]
Downloads and Videos
[ZIW440 Parts Schematic]
